APIOpen Network Video Interface (Profile S), ISAPI, SDK
ClientiVMS-4200, Hik-Connect
SecurityPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS,security audit log, TLS 1.2, host authentication (MAC address)
Interface
Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
General
MaterialMetal & Plastic
WeightApprox. 330 g (0.7 lb.)
Power12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plug PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W
DimensionØ110 mm × 92.4 mm (Ø4.3" × 3.6")
LanguageEnglish, Ukrainian
General FunctionAnti-flicker, heartbeat, mirror, password protection, password reset via e-mail
Startup and Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Package Dimension150 mm × 150 mm × 141 mm (5.9" × 5.9" × 5.6")
With Package WeightApprox. 530 g (1.2 lb.)
DORI
DORI2.8 mm, D: 81 m, O: 32 m, R: 16 m, I: 8 m 4 mm, D: 106 m, O: 42 m, R: 21 m, I: 11 m
Approval
EMCFCC (47 CFR Part 15, Subpart B) CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014) RCM (AS/NZS CISPR 32: 2015) IC (ICES-003: Issue 7) KC (KN32: 2015, KN35: 2015)
SafetyUL (UL 62368-1) CB (IEC 62368-1: 2014+A11) CE-LVD (EN 62368-1: 2014/A11: 2017) BIS (IS 13252 (Part 1): 2010/IEC 60950-1: 2005)
ProtectionIP67 (IEC 60529-2013)
EnvironmentCE-RoHS (2011/65/EU) WEEE (2012/19/EU) Reach (Regulation (EC) No 1907/2006)
Event
LinkageNotify surveillance center, trigger capture
Basic EventMotion detection , video tampering alarm, exception
